Four generations of full heat purification integrated machine.

Commercial fresh air purification series：

Feature:

Fresh air heat exchange and purification are combined into one, and the air is efficiently purified while introducing fresh air

1. Efficient air supply: Using high-quality DC motors with independent intellectual property rights, energy efficiency is increased by 5%, and the output is automatically increased when the output resistance increases with constant air volume and high static pressure

2. Super silent: DC inverter motor.

3. One second maintenance: Completely solve the problem of inconvenient maintenance of the ceiling equipment in the later stage, and open the inspection port without tools, and truly achieve one-second maintenance

4. Intelligent control：Comprehensive upgrade of intelligent control to achieve multiple control modes: temperature display, humidity display, air quality (PM2.5/TVOC? CO2) display. Automatic/manual mode switching, timing switch, filter maintenance reminder, stepless speed regulation, independent control of dual fans.

Performance parameters of all-in-one heat purification machine series (fourth generation)

Model	Product name	Air volume（M3h）	Static pressure (pa)	Noise (dB)	Input power(W)	Supply power	Wind open(mm)	Net weight(kg)	Purification efficiency	Filter size(mm)
AMTQR150H-4-3.3	150 All-in-one heat purification machine	150	85	35		220V/50Hz	Ф100		99%	Primary efficiency：19820420
										Medium efficiency：19820420
										High efficiency：19820450
AMTQR250H-4-3.3	250 All-in-one heat purification machine	250	95	36		220V/50Hz	Ф150		99%	Primary efficiency：27820420
										Medium efficiency：27820420
										High efficiency：27820450
AMTQR350H-4-3.3	350 All-in-one heat purification machine	350	100	38		220V/50Hz	Ф150		99%	Primary efficiency：37820420
										Medium efficiency：37820420
										High efficiency：37820450
AMTQR500H-4-3.3	500 All-in-one heat purification machine	500	120	40		220V/50Hz	Ф200		99%	Primary efficiency：52824420
										Medium efficiency：52824420
										High efficiency：52824450

Note: The product is constantly improving and updating, please refer to the actual product.

All-in-one heat purification machine series size parameters

Model	A	B	C	ФD	E	F	G	H	I
AMTQR150H-4-3.3	948	992	1088	520	480	550	235	268.5	Ф100
AMTQR250H-4-3.3	948	992	1088	600	560	630	235	268.5	Ф150
AMTQR350H-4-3.3	948	992	1088	700	660	730	235	268.5	Ф150
AMTQR500H-4-3.3	1148	1192	1308	850	810	880	275	308.5	Ф200
