Fin Heat Exchanger
Total 1 página 15 archivos
Dry coolers(fin heat exchangers) are available in a wide performance range between approx. 5 and 2,000 kW dry cooling performance. Depending on case of application, you can select between different series. All dry coolers(fin heat exchangers) are available in different noise levels and naturally suitable for outside installation. Water or water-glycol mixtures can be used as cooling medium.
In case you do not find the type or model in the website, we can customized according to your request. Please contact us:Tel: 0086-21-35324169, Fax:0086-21-35324166, Email:sales@shenglintec.com
In case you do not find the type or model in the website, we can customized according to your request. Please contact us:Tel: 0086-21-35324169, Fax:0086-21-35324166, Email:sales@shenglintec.com
| Structure Type | Model | Photo | Cooling cpacity (kw) | Air volume (m3/h) | Fan Diameter(mm) | Air discharge direction | Key documents |
|---|---|---|---|---|---|---|---|
| Plate Type Dry Cooler(Fin Heat Exchanger) | SHSL-D1-005-1x350~SD1-649-16x630 |
 |
5~649 | 2828~263503 | 350~630 | Vertical | Brochure of SHSL-D1 |
 |
Horizontal | ||||||
| V Type Dry Cooler(Fin Heat Exchanger) | SHSL-D2-148-4X630~SD2-921-20x630 |
 |
148~921 | 76459~351663 | 630 | Vertical | Brochure of SHSL-D2 |
| Plate Type Dry Cooler(Fin Heat Exchanger) | SHSL-D3-042-1X800~SD3-607-12X800 |
 |
42~607 | 21454~227449 | 800 | Vertical | Brochure of SHSL-D3 |
| V Type Dry Cooler(Fin Heat Exchanger) | SHSL-D4-176-4X800~SD4-792-16X800 |
 |
176~792 | 21454~227449 | 800 | Vertical |
Brochure of SHSL-D4 |
