Product Description
Green Standard Immersion Coolant is made of hydrocarbon and other materials refined. This product can be used directly.
Features and Usages
• Excellent electrical insulation performance, to ensure the safety performance of data centres and energy storage power stations, voltage resistance up to 35KV or more;
• Excellent thermal conductivity, low kinematic viscosity, good fluidity performance, to improve the level of immersion temperature control system temperature control;
• High flash point to ensure that the battery will not burn when the temperature is too high, to improve the safety of data centres and energy storage power stations;
• Excellent metal anti-corrosion performance and non-metallic compatibility, extending the service life of the immersion temperature control system;
• Excellent anti-freezing performance, preventing equipment damage caused by liquid freezing and expansion;
• Meet the requirements of EU RoHS, REACH and other regulations.
|
PROPERTIES
|
TYPICAL DATA
|
TEST METHOD
|
|
Appearance
|
Clear and transparent,
no sediment and suspension
|
Visual estimation
|
|
Density（25℃），g/cm3
|
0.803 |
GB/T 1884
|
|
Kinematic viscosity（40℃）
/（mm2/s） |
14.25 |
GB/T 265
|
|
Pour point/℃
|
-50 |
GB/T 3535
|
|
Flash point (opening)/℃
|
229.6 |
GB/T 3536
|
|
Ignition point/℃
|
291.0 |
GB/T 3536
|
|
Breakdown voltage （2.5mm）
/kV |
38.2 |
GB/T 507
|
|
Volume resistivity（60℃），Ω·m
|
2.05*10^13 |
DL/T 421
|
|
Relative dielectric constant（90℃）
|
2.012 |
GB/T 5654
|
|
Dielectric loss factor
|
0.42 |
GB/T 5654
|
|
Acid value/ mg/g KOH
|
0.012 |
GB/T 264
|
|
Copper corrosion（100℃，3h）
|
1b |
GB/T 5096
|
|
Thermal conductivity（40℃,W/m.K）
|
0.1460 |
ASTM D2717
|
|
Specific heat capacity（40℃,J/g.K）
|
2.16 |
ASTM E2716
|
|
Density correction factor（(g/cm3)/℃）
|
0.000673 |
ASTM D1250
|
|
Vapour pressure（150℃，mm/Hg）
|
0.2 |
ASTM D2879
|
Temperature control systems for immersed data centres and immersed energy storage batteries.
