SHENGLIN Rooftop Air Conditioners for Export Markets

Date:2026-10-19 Rooftop units combine cooling, heating and ventilation in a single self contained package, making them a popular choice for residential, office and retail buildings where floor space is limited and installation speed matters. SHENGLIN's rooftop air conditioners are engineered for these demands, with capacity from 6 to 12.5 tons and efficiency aligned to European export requirements.


Product Specifications

1. Cooling capacity: 6–12.5 Tons / 22–43kW / 75,000–150,000 BTUs
2. Energy efficiency: 2.7–3.3 COP
3. Compressor warranty: 3 years limited; other parts: 1 year limited
4. Designed to European export standards (CE / ErP aligned)




Robust, Weather Resistant Construction

Panels and frame are made of galvanized steel protected with polyester powder paint, ensuring total resistance to atmospheric agents. Direct expansion coils sit above a condensate drain tray, keeping moisture management clean in daily operation.


Quiet, Efficient Compression

The full range uses high efficiency hermetic scroll compressors, each fitted with a built in thermal overload cut out and crankcase heater and mounted on rubber vibration dampers. Ripple type acoustic insulation covers the compressor section, while thermal insulation protects the coil and fan sections — keeping sound levels low in occupied spaces.


Airflow Designed Around the Building

Forward curve centrifugal fans serve the air treatment section, with axial fans on condensation. Air discharge can be arranged from the front, side or underside, and high external pressure rating supports long duct runs. A straightforward line controller provides Cooling, Heating and Auto modes, error indication and timed on/off, backed by an electric panel with breakers, contactors and a phase sequence relay.


Configured for Project Requirements

The platform supports options that extend its scope: an economizer with fresh and return air dampers, free cooling and a low ambient control device for operation from below 20°C down to -10°C, BMS integration, T3 tropical climate rating, condenser coil guards, roof curbs, metal or aluminum filters, G4 plate and bag filters, water heating coils and upgraded fan motor drives.


Warranty and Applications

The range is backed by a 3 year limited warranty on the compressor and 1 year limited coverage on other parts, and is suited to residential, office building and shopping mall applications.

For specifications or project inquiries, please feel free to contact SHENGLIN.
