Coil
Stainless Steel Cooling Coil
  • Stainless Steel Cooling Coil
  • Stainless Steel Cooling Coil
  • Stainless Steel Cooling Coil
  • Stainless Steel Cooling Coil

Stainless Steel Cooling Coil

In case you do not find the type or model in the website We can customized according to your request.
Contact Now
  • Features
  • Technical Data
  • Application
  • Certification
  • Part List
● Cooling Esthetic lasers
● Cooling medical lasers
● Cooling welding lasers
● Cooling metal cutting lasers.

We are a professional heat exchanger, condenser, evaporator and heat pump manufacturerin China.
Our products have been exported to Europe,USA, Japan and Middle east etc.

Main Features:
1. material :stainless steel , aluminum ,
2. aluminum foil: hydrophilic or bare
3. fin type: louver fin or flat fin or corrugated fin
4. stainless steel tube: 9.52mm.
5. pitch of fins can be adjusted between 1.8—5.8mm.
6. pitch of holes and pitch of rows : 25*21.65MM and 12.7*19.05MM
8. voltage: 220V/1/50HZ and 380V/3/50HZ or 120V/50HZ.
9. different alternative condensing fans available: shaded pole or outer rotor fan motor.
10.did gas examination under 3.0Mpa air pressure to ensure the tightness.
11.condenser type:single fan, double fan, triple fan and fourfold fan
12.widely used in refrigeration industry, water cooling system.
13. we can supply products as per customized samples or drawing.
14.1/4 hp,1/3hp,1/2hp.....
15. It is widely used in Food machinery,medical equipment.




Item
Condenser Type
Operation medium
Operation pressure (MPa)
Application
1 Φ16/Φ9.52/Φ12.7 Copper tube with aluminium fin
Cold/hot water
1.6
Used for combined air handling unit, fan coil etc air conditioning devices
2 Φ18/Φ20 Steel pipe winding with steel sheet
Steam
0.2
Used for combined air handling unit, fan coil etc air conditioning devices
3 Φ16/Φ9.52/Φ12.7 Copper tube with aluminium fin
Brine
1.6
Used for heat transfer in cold storage and all kinds of low temperature systems
4 Φ9.52/Φ7.94/Φ7 Copper tube with aluminium fin
Ethylene glycol
1.6
Used of energy recovery and low temperature system devices
5 Φ16 Copper tube with aluminium fin
Ice mud
1.6
Used for dry operation condition, fresh air dehumidification etc systems
6 Φ9.52/Φ7.94/Φ7 Copper tube with aluminium fin
R22
1.9
Used for industry and commerce air conditioning system
7 Φ9.52/Φ7.94/Φ7 Copper tube with aluminium fin
R407C
1.9
Used for industry and commerce air conditioning system
8 Φ9.52/Φ7.94/Φ7 Copper tube with aluminium fin
R134a
3.1
Used for vehicle and vessel etc transportation devices
